Exoracing Silver Sewn Heat Sleeve 0.5m
Exoracing Silver Sewn Heat Sleeve 0.5m
SKU:
10 in stock
Why use our sewn heat sleeve?
If you have a high-performance vehicle, you know the extreme temperatures you will face in your engine bay. One of the main problems that excess heat in your engine bay will create is making your hoses, lines, and wiring looms brittle and fail over time.
Our Exoracing sewn heat sleeve is the perfect solution for this problem. With its excellent heat-reflecting properties, you can rest assured that your lines and hoses will remain in top condition.
Exoracing sewn heat sleeve is a top-tier, reliable solution constructed from lightweight polymer-laminated glass cloth that can withstand continuous radiant heat of up to 600°C and won't melt until it's reached over 1000°C!
Our main priorities have been our heat sleeve's ease of use and effectiveness. Our sewn heat sleeve is easy and quick to install—simply push the sleeve over the lines you need to protect.
Once fitted, you can rest assured that you have done everything possible to prevent heat soaking and provide long-lasting protection for your oil feed lines, drain lines, coolant lines, and anything else that might need protection from the heat.
When ordering your Exoracing sewn heat sleeve, you can purchase it in uncut lengths of 0.5m; for example, if you select a quantity of 4, you will receive one 2m sleeve length. Once you have obtained your sleeve, you can easily cut it down to the required size with sharp scissors.
When you order an Exoracing sewn heat sleeve, you not only receive a high-quality, practical heat management item, but with our Exoracing logo stitched on, you are showing support for your favourite performance aftermarket brand.
Please don't get caught out by the effects of extreme heat cycles in your engine bay. It could be the difference between winning that race against James in his ST150 or sitting at the side of the road with your oil on the floor, wondering where it all went wrong.
Purchase includes:
- 1 x Exoracing Sewn Heat Sleeve
- 1 x Exoracing Lifetime warranty
Features:
- Protects engine bay components
- Lightweight polymer-laminated glass cloth construction
- Easy to cut to length
- Long-lasting solution for your heat management
- Available up to a continuous 20m length
- Available in a wide range of diameters
- Maximum continuous radiant temperature: 600°C
- Maximum continuous direct temperature: 240°C
- Installation is quick and easy
- Exoracing Lifetime Warranty
Sewn Heat Sleeve Installation Guide:
Installing our Sewn Heat Sleeve couldn't be easier! Just follow these few steps below:
- Measure how much of your line/hose you want to cover with the heat sleeve.
- Cut the heat sleeve down to the correct length using a pair of sharp scissors.
- Feed the heat sleeve over the line/hose
- If the sleeve is tight enough, no securing will be needed.
- If you need to secure the heat sleeve, attach a metal cable tie, heat shrink or wire at either end of the heat sleeve.
Technical Specifications:
Minimum Temperature | -40°C |
Maximum continuous Direct temperature | 260°C |
Maximum continuous Radiant temperature | 600°C |
Melting Temperature | 1100°C |
Material | Lightweight polymer-laminated glass cloth |
Chemical Resistance | Hydraulic Fluids, fuels and oils. |
Colour | Silver |
Maximum Length | 20m |
Cutting Tool | Scissors |
Warranty | Exoracing Lifetime Warranty |
Available ID sizes |
15mm, 20mm, 25mm, 30mm ID |
Notes:
- If you are looking for protective heat sleeving that can cover items with a tight radius, it is recommended that you order the next size up.
